Expanded PTFE cord

Expanded PTFE Round Cord

TCI Expanded PTFE cord is made of 100% pure expanded PTFE, used as valve-spindle and flange seals in the chemical, pharmaceutical and food processing industries. Flanges are sealed quickly and securely by simple insertion of a ring of PTFE round cord (Ends twisted).

Typical Application
 Acids, alkalis, solvents, gases,etc.
  Especially suitable for sealing flange connections, pip systems, hydraulic and pneumatic systems, etc. In addition, it's a good ideal for seals in glass, enamel and plastic flanges, vessels and special shaped sealing surface.

Prime Features
 Clean, non-contaminating and graphite free
  Long maintenance free service life
 Minimal shaft wear and leakage
  Save money and time.

Sizes
 3mm Dia
4mm Dia
5mm Dia
6mm Dia
7mm Dia
8mm Dia
9mm Dia
10mm Dia
12mm Dia
14mm Dia
16mm Dia

Technical Data

Material	100% Expanded PTFE
Temperature Range	-150 up to +260 oC
Process	100 bar
Shaft Speed	10m/s
PH	0~14
Density	0.70~0.80 g/cm3
